EVD CS4.2TB (40W, 4″ Weather-resistant Loudspeaker)

SKU: CS4.2TB Category: Brand:
Share On:

EVD CS4.2TB

40W 4″ Weather-Resistant Loudspeaker

The EVD CS4.2TB is a two-way loudspeaker system with weather-resistant housing. Fitted with one 4″ mid-woofer and one 0.8“ (20mm) dome tweeter, also equipped with multi-tap transformer. The system conforms to IP46 international standard.

FEATURES

  •       Sturdy Plastic Injection Moulding Cabinet
  •       IP46 rating : Highly weather-resistant
  •       High Power Output
  •       Mounting Bracket & Safety Chain Included

APPLICATIONS

  •       Background Music or Public Addressing (P.A)
  •       Office  : Conference System, Meeting Rooms
  •       Shops   : Retail Outlets, Restaurants, Al Fresco Area
  •       Outdoor  : Water Parks, Swimming Pools, Garden
Brand

EVD

Specification

Model No. CS4.2TB
Frequency Response 75 Hz – 20 kHz (-3dB)
Drivers 1x  4″(100mm) / 1“(25mm) Voice Coil LF

1x  0.8″(20mm) / Dome Tweeter

Input Voltage 100 V
Rated Power 10W / 20W / 40W / OFF / 16Ω
Sensitivity 88 dB 1W/1M
Maximum SPL 103 dB Continuous, 109 dB Peak
Impedance 16 Ohms Nominal
Dispersion (-6dB) 120° x  90°
Crossover Frequencies 3.5 kHz Passive
Dimensions 141mm (W) x 170mm (D) x 230mm (H)
Weight 2.8 kg
