dB Technologies RDNET CONTROL 2
Master Control Unit
The RDNET system was purposely developed to create a data network for monitoring and command of more systems.
The RDNET CONTROL 2 unit can manage up to 2 subnets. Up to 32 devices can be connected to each subnet (2 subnets x 32 = total 64 devices).
The addressing of the various devices is handled automatically by RDNET CONTROL 2 interface.
Each device is assigned a unique address during the power on procedure of network.
Technical Specifications:
| Network | standard EIA RS-485 |
| up to 2 managed subnet | |
| max. 32 devices connected to each subnet | |
| RDNET connections | 2 RJ 45 connectors (EtherCon) for CAT 5 cable |
| 2 three-pole XLR socket (as alternative to RJ 45) | |
| PC connection | USB (type B) |
| Power supply | powered by USB Type B socket |
| Mechanical characteristics | ABS Plastic BOX, Black color |
| Dimensions (WxHxD) : 111 x 40.5 x 89.5 mm | |
| Net weight : 175 gram |
